Ozone Mach1 Foil Kite
IN A NUTSHELL...
Developed from the R1 V4 and Chrono DNA, the Oxone Mach 1 sets a new benchmark for freeride performance possibilities, especially in lighter winds.
Design details
Sizes: 7 / 9 / 11 / 13 / 15 / 18
Go much bigger and faster in less wind. This is THE gateway for advanced freeriders to enjoy even more epic sessions while rediscovering the awesome sensation of kite power that got them hooked in the beginning.
Ozone have taken the most powerful elements of race kite design and re-tuned them to suit a wider range of riders, delivering rocket-fuelled big air twin-tip performance and fluid, high-speed riding on a hydrofoil.
PERFORMANCE
- High-performance all-round foil kite
- Amazing jumping and hangtime, even in light winds
- R1 race kite design base, re-tuned for all-round freeriding
- Increased accessibility, but some suitable experience still required
TUNING AND DESIGN
- High-aspect-ratio design
- Designed to fly on 17m or 21m lines
- 4 bridle line levels for ease of use, control and longevity
- Sheathed bridle lines for easy set-up and durability
- Lightweight but durable construction
- Transverse sail shaping
WHO IS IT FOR?
- Riders with prior experience using foil kites who are ready for more performance.
- Twin-tip riders focused on big air and boosting performance.
- Freeride foilers who want a high-performance kite that adapts to various riding styles.
KEY FEATURES AND DESIGN
Higher-Aspect-Ratio
Improved efficiency, greater hangtime and increased performance in light winds.
Refined Bridle System
Reduced bridle attachment points for easier setup while maintaining stability and control.
Durable Material Selection
Harder-wearing canopy and thicker bridle materials reduce tangles and increase longevity while maintaining lightweight performance.
Smooth & Progressive Power Delivery
Linear power output makes for more controlled and predictable handling.
Optimized for Different Line Lengths
Works exceptionally well with the advised 17 or 21m line lengths, adapting to riding style and conditions.
WHY HAS THE MACH1 REPLACED THE CHRONO IN THE OZONE RANGE?
Given that our latest high-performance hydrofoil race kite, the R1 V5, is now highly specialised for hydrofoil racing with a two-line setup, minimal overhead lift and is built with ultra-lightweight materials, we saw an opportunity to merge race kite performance with freeride durability. We wanted to create a robust machine that excels in big air while maintaining the efficiency that tube kites can’t match.
When the R1 V4 was still current, many advanced twin-tip riders were choosing its high-aspect design for big air and hangtime.
Recognising the demand for a freeride foil kite with race-like performance, we took the DNA of the R1 V3 & V4 models and re-tuned things — removing race-specific constraints while reinforcing durability and enhancing big air capability.
Tech specs
Factory Ownership Advantage
Ozone uniquely owns its own factory where all kites, wings, boards, hydrofoils, paragliders, speed wings and accessories are made. Guaranteeing hand checked quality control and the finest materials at every step, there are also excellent working conditions for all 1000 employees.
Designed with OZ-CAD
The future is now. All Ozone kite and wings are designed with our own highly advanced custom built CAD software that we control and modify with each new product design. Allowing for specifically tailored technical developments, our designers can maximise performance while also minimising waste.
Single-Layer Laser Cut
Ozone kites and wings are crafted with exceptional precision using advanced laser technology to cut each panel individually in a single layer. This meticulous approach ensures consistent accuracy across all products, from entry level to high performance models. Our commitment to high standards in production reflects our dedication to delivering reliable, high-quality equipment for riders at every level.
High Performance Ultra Light Materials
Durable, airtight and lightweight double rip-stop Nylon material for the upper and lower surfaces. The material has a unique formulated coating to help shed water, improving flying characteristics and water re-launch.
Transverse Sail Shaping
The Leading Edge now features Transverse Sail Shaping creating a cleaner surface on the most important area of the aerofoil. The result is less turbulent airflow and longer skin adhesion, which positively effects the lift to drag ratio increasing overall performance.
Leading Edge Profile Battens
The Leading Edge is reinforced with flexible lightweight plastic battens to maintain the shape of the profile during angle of attack changes and turbulent airflow. This drastically improves overall performance as the foil remains true to the designed shape.
High Cell Count
A high number of cells controls ballooning between the ribs, holding the wing shape and designed surfaces smoother and more accurately. This reduces turbulent airflow, providing more efficiency, speed and de-power for increased overall performance.
Optimized Leading Edge Air Intakes
The Leading Edge air intakes have been refined for faster progressive inflation, improved seal and optimised positioning to maintain internal air pressure. This enhances land and water re-launch capabilities.
Internal Diagonals and Straps
Internal span-wise straps work in unison with optimized diagonal ribs, distributing load from the bridles evenly and effectively. This increases the internal structural balance that helps control the high aspect ratio, while allowing the top and bottom surfaces to maintain the designed profile without being distorted from indirect tension or loads.
Sheathed Dyneema Bridle Lines
High quality, low stretch sheathed bridle lines for maximum strength and performance. This is the same line we have used on our Snowkite range for over 10 years
Double pulley Speed System
Using high spec low friction Ronstan Orbit pulleys to reduce wear and rider fatigue while improve feeling and performance of the kite.
Water Drainage Channels & Valves
An internal channel is shaped into the end of each cell along the trailing edge. This allows loose sand or water to run between the cells and out of the tips during flight. Drainage valves at both wing tips seal to keep air in, and open up when water needs to drain out. The Velcro sealed tips can be opened for cleaning the kite. Always clean your kite by emptying any water, sand or dirt as this will prolong the life of the kite and help it fly as designed.
Waterproof deflation zipper
Intelligently positioned for easy deflation and pack down.
Tuned Bridle Geometry
We work extensively during our R&D process to develop the size range to feel in tune with each other. Every kite has a unique bridle layout, individually tested and fine-tuned to maximize the feeling and performance.
Fool proof line connectors
Fool proof line connectors prevent incorrect rigging of the flying lines to the kite.
Closed Cell Foil Kite Technical Bag
Technical Bag with loads of space featuring an internal stash pocket and external control system pocket. Adjustable shoulder straps and foam padding provide extra comfort.
Closed Cell Foil Kite Compressor Bag (optional)
For a secure packing process to maintain the plastic pattern profile shape. Light weight materials, internal compression straps and a breathable mesh lining keep weight and packing size to a minimum - perfect when traveling with multiple kites. Combine with the Technical Bag to fit multiple kites inside one bag.
